It is mainly used for counting the number of untwisting turns of steel cord samples. The untwisting direction is selected through the control panel, and the number of untwisting turns is automatically recorded and the increased length after untwisting can be observed.

Equipment use:

Mainly used for counting the number of untwisting turns of steel cord samples. The untwisting direction can be selected through the control panel, and the number of untwisting turns can be automatically recorded and the length increase after untwisting can be observed

Technical parameters:

Control mode: control panel button

Rotation speed: 0-40rpm (adjustable)

Sample range: diameter 0.2-3mm

Maximum push stroke: 150mm

Machine specifications: 1130*255*845 (width, depth and height)

Motor power: 120W speed-adjustable motor

Power supply: AC220V/50HZ

Complies with the requirements of GB/T33159 "Steel Cord Test Method" and GB/T11181-2016 "Steel Cord for Radial Tires"
